| Nominal Cross Section (mm2) | Conductor Structure (Roots/Wire Diameter, mm) | Insulation Thickness (mm) | Outer Diameter Control (mm) | Package Length (m) |
|---|---|---|---|---|
| 0.5 | 7 × 0.30 | 0.5 | 2.3 ± 0.3 | 200 |
| 0.75 | 11 × 0.30 | 0.5 | 2.5 ± 0.3 | 200 |
| 1 | 14 × 0.30 | 0.5 | 2.6 ± 0.3 | 200 |
| 1.2 | 40 × 0.19 | 0.5 | 2.7 ± 0.3 | 100 |
| 1.5 | 21 × 0.30 | 0.5 | 2.9 ± 0.3 | 100 |
| 2 | 28 × 0.30 | 0.6 | 3.3 ± 0.5 | 100 |
| 2.5 | 35 × 0.30 | 0.6 | 3.6 ± 0.5 | 100 |
| 4 | 56 × 0.30 | 0.8 | 4.7 ± 0.5 | 100 |
| 6 | 84 × 0.30 | 0.8 | 5.5 ± 0.5 | 100 |
| 10 | 84 × 0.40 | 0.8 | 6.6 ± 0.5 | 100 |
| 16 | 228 × 0.30 | 0.8 | 7.8 ± 0.5 | 100 |
| 16 | 126 × 0.40 | 0.8 | 7.8 ± 0.5 | 100 |
| 25 | 196 × 0.40 | 0.8 | 9.5 ± 0.5 | 100 |
| 25 | 361 × 0.30 | 0.8 | 9.5 ± 0.5 | 100 |
| 35 | 494 × 0.30 | 1.0 | 11.2 ± 1.0 | 100 |
| 50 | 396 × 0.40 | 1.2 | 13.2 ± 1.0 | 100 |
| 50 | 703 × 0.30 | 1.2 | 13.2 ± 1.0 | 100 |
| 70 | 551 × 0.40 | 1.2 | 15.4 ± 1.0 | 100 |
| 70 | 988 × 0.30 | 1.2 | 15.4 ± 1.0 | 100 |
| 95 | 760 × 0.40 | 1.2 |
